Counter Cooler GN1/1

CK7210X1

Item no.: 54291 (Substitution for 17674 CK7210/-SP)

  • Stainless steel
  • Ventilated cooling
  • Controller with Bluetooth and NFC connectivity
  • Automatic defrost
  • Self-closing doors
  • Removable table top without splashback
  • Adjustable legs
Energy arrow
Product Sheet

Technical specifications

Measures and Content

  • Temperature Range
    -2 to +8 °C
  • Climate Class
    5
  • Gross / Net Weight
    113 / 98 kg
  • Gross / Net Volume
    238 / 190 l

Design and Material

  • Feet / Legs
    4 adjustable legs
  • Exterior Finish
    SS304
  • Interior Finish
    SS304
  • Lock
    No
  • Door No & Type
    2 hinged self-closing doors
  • Shelves No & Type
    2 wire shelves white
  • Shelf Color
    White

Cooling and Functions

  • Type of Controller
    Electronic
  • Type of Cooling
    Ventilated
  • Type of Defrost
    Automatic
  • Refrigerant
    R600a
  • Refrigerant Charge
    95 g
  • Thermometer

Power and Consumption

  • Energy Class
    A
  • Energy Consumption
    1.03 kWh/24h
  • Annual Energy Cons.
    376 kWh/year
  • Input Power
    300 W
  • Voltage / Frequency
    220-240/50-60 V/Hz
  • Noise Level
    38 dB(A)

Dimensions

  • Internal Dimension (WxDxH)
    799 x 580 x 564 mm
  • External Dimension (WxDxH)
    1360 x 700 x 860 mm
  • Packed Dimension (WxDxH)
    1390 x 730 x 910 mm
  • 40ft Container Load
    48 pcs
  • GTIN / EAN
    5708181739287

Downloads

Description

Spare parts

  • 2
    Item no. 14071Thermostat XW60LRH
  • 4
    Item no. 32928Lock, Screwdriver Operated
  • 6
    Filter 160x200
    Item no. 10019Filter 160x200
  • 9
    Door Bushing For 7,6 mm Pin
    Item no. 12780Door Bushing For 7,6 mm Pin
  • 11
    Filter Drier 20 G
    Item no. 15723Filter Drier 20 G
  • 13
    Item no. 54799Condenser
  • 15
    Evaporator/Condensor Fan 4650
    Item no. 14475Evaporator/Condensor Fan 4650
  • 16
    Item no. 33848Basket Guard Grill 2021 Version
  • 17
    Item no. 51599Water Box
  • 18
    Item no. 54800Evaporate pipe
  • 19
    Item no. 54785Lower Hinge Right
  • 20
    Item no. 32429Compressor ETH110L R600a
  • 21
    Item no. 54801Suction pipe
  • 22
    Item no. 51602Front Panel Hinge
  • 23
    Item no. 51603Lock Hook
  • 24
    Item no. 54750Leg 150-210 mm (4pcs) - After 03-2024
  • 26
    Item no. 54802Top
  • 27
    Item no. 54789Unit room cover
  • 29
    Item no. 51616Top Fixed Board
  • 30
    Item no. 51617Up Hinge Front Panel
  • 31
    Evaporator Water Pan
    Item no. 11535Evaporator Water Pan
  • 32
    Evaporator
    Item no. 14257Evaporator
  • 33
    Item no. 34231Fan Support 13459
  • 34
    Item no. 54803Circuit Fan
  • 35
    Item no. 51607Evaporator Cover
  • 36
    Item no. 51608Air Flow Conduct Board
  • 37
    Item no. 32023Sensor Clip For CK-I
  • 39
    Back Support for drawer- Left 2020
    Item no. 34460Back Support for drawer- Left 2020
  • 40
    Front Support for drawer- Left 2020
    Item no. 34461Front Support for drawer- Left 2020
  • 41
    Item no. 51609Guide Left
  • 42
    Item no. 54792Shelf
  • 43
    Gasket 388 x 598 mm
    Item no. 12622Gasket 388 x 598 mm
  • 44
    Item no. 55849Door Left
  • 45
    Item no. 34236Door Spring Hinge 12937
  • 51
    Item no. 51610Guide Right
  • 52
    Item no. 54794Door Right
  • 53
    Front Support for drawer- Right 2020
    Item no. 34459Front Support for drawer- Right 2020
  • 54
    Back Support for drawer- Right 2020
    Item no. 34458Back Support for drawer- Right 2020
  • 55
    Down Hinge Left
    Item no. 12829Down Hinge Left
  • 56
    Item no. 51624Middle Bridge
  • 57
    Top Hinge Right 2016
    Item no. 12989Top Hinge Right 2016
  • 58
    Top Hinge Left 2016
    Item no. 12976Top Hinge Left 2016
  • 59
    Item no. 51614Sensor
  • 59
    Item no. 51615Sensor
  • 60
    Item no. 51618Waterproof Plate
  • 61
    Item no. 32026Drain Pipe
  • 62
    Item no. 32027Drain Pipe Clip
  • 63
    Item no. 54796Door Switch
  • 64
    Item no. 54797Bottom Shelf Side
